Electric welding machine

◉ Product Details

Product Model:	TIG-250/270/280/300/400CT
Product Description:	Constant Current Output/Inverter Energy Saving/Air Cooling/DC Output/Adjustable Current/Adjustable Backgas Time
Scope of application:	Small hardware manufacturing / stainless steel doors and windows manufacturing / household kitchenware, furniture processing
Rated Input Voltage:	220V
Rated input capacity:	TIG:	7.8KVA
	MMA:	8.5KVA
Frequency:	50-60Hz
No-load Voltage:	68V
Load duration rate:	60%
Welding wire：	1.6-2.0mm
Insulation class:	Class F
Protection level:	IP21S
Output current:	TIG:	10-230A
Output current:	MMA:	10-190A
Size and weight:	Product Dimension:	380150300mm
	Poduct Weight:	7.6kg
	Package Dimension:	450280350mm
	Package Weight:	11kg
Accessories:	Standard accessories:	One 4m argon arc welding gun 1 set of 3M ground wire clamp 1 tungsten needle One hexagon wrench 1 quick plug 2 throat hoops
	Optional accessories:	Welding cap Argon gauge Fragile Parts
Particular attention:the optional accessories is required extra cost, if you need them, please inquiry factory before placing order
